304 Fieldbus control with the embedded fieldbus
The table below and the state diagram on page 306 describe the Status word content
for the ABB drives profile. The upper case boldface text refers to the states shown in
the diagram.
12 MOTOR_HEAT 1 Start motor heating.
0 Stop motor heating. See parameter 2115, option COMM.
13…
15
Reserved
ABB drives profile (EFB) Status word, parameter 5320 EFB PAR 20
Bit Name Value STATE/Description
(Correspond to states/boxes in the state diagram)
0 RDY_ON 1 READY TO SWITCH ON
0 NOT READY TO SWITCH ON
1 RDY_RUN 1 READY TO OPERATE
0 OFF1 ACTIVE
2 RDY_REF 1 OPERATION ENABLED
0 OPERATION INHIBITED
3 TRIPPED 0…1 FAULT. See chapter Fault tracing on page 311.
0 No fault
4 OFF_2_STA 1 OFF2 inactive
0 OFF2 ACTIVE
5 OFF_3_STA 1 OFF3 inactive
0 OFF3 ACTIVE
6 SWC_ON_INHIB 1 SWITCH-ON INHIBITED
0 Switch-on inhibit not active
7 ALARM 1 Alarm. See chapter Fault tracing on page 311.
0 No alarm
8AT_SETPOINT1 OPERATING. Actual value equals reference value (= is
within tolerance limits, ie the difference between the output
frequency and the frequency reference is less than or equal
to 4/1%* of the nominal motor frequency).
* Asymmetric hysteresis: 4% when frequency enters the
reference area, 1% when frequency exits the reference
area.
0 Actual value differs from reference value (= is outside
tolerance limits).
9 REMOTE 1 Drive control location: REMOTE (EXT1 or EXT2)
0 Drive control location: LOCAL
ABB drives profile Control word, parameter 5319 EFB PAR 19
Bit Name Value Comments
