Parameters 201
31.05 External event 3
source
Defines the source of external event 3. See also
parameter 31.06 External event 3 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.06 External event 3 type Selects the type of external event 3.
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.07 External event 4
source
Defines the source of external event 4. See also
parameter 31.08 External event 4 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.08 External event 4 type Selects the type of external event 4.
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.09 External event 5
source
Defines the source of external event 5. See also
parameter 31.10 External event 5 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.10 External event 5 type Selects the type of external event 5.
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.11 Fault reset selection Selects the source of an external fault reset signal. The
signal resets the drive after a fault trip if the cause of the
fault no longer exists.
0 -
>
1 = Reset
Note: A fault reset from the fieldbus interface is always
observed regardless of this parameter.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Timed function 1 Bit 0 of 34.01 Timed functions status
.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
Supervision 1 Bit 0 of 32.01 Supervision status. 24
Supervision 2 Bit 1 of 32.01 Supervision status. 25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
