32 Control macros
Reference from the integrated panel.
1)
In scalar control (default): See parameter group 28 Frequency reference chain.
In vector control
: See parameter group 22 Speed reference selection.
Select the correct control mode from the Motor data view or with parameter 99.04
Motor control mode.
2)
3)
Ground the outer shield of the cable 360 degrees under the grounding clamp on
the grounding shelf for the control cables.
Input signals
• Start/Stop selection (DI1)
• Forward (0) / Reverse (1) (DI2)
• Speed selection (DI3)
• Speed selection (DI4)
• Ramp set 1 (0) / Ramp set 2 (1) selection (DIO1)
• Output frequency or motor speed reference (AI1)
Output signals
• Output frequency (AO)
• Ready to run (0) / Not ready (1) (DIO2)
• No Fault [Fault (-1)]
DI3 DI4 Operation/Parameter
Scalar control (default) Vector control
0 0 Set frequency through AI1 Set speed through AI1
1028.26 Constant frequency 1 22.26 Constant speed 1
0128.27 Constant frequency 2 22.27 Constant speed 2
1128.28 Constant frequency 3 22.28 Constant speed 3
DIO1 Ramp set Parameters
01 28.71 Freq ramp set selection,...,
28.74 Freq acceleration time 212
