422 Fieldbus control through the embedded fieldbus interface (EFB)
Manufacturer specific profile area (2000...5FFF)
Index
Sub-
index
Name Type Access Description
2000h 0 Number Of
Entries
U8 RO
3 REFERENCE
2
INT16 RWW Transparent 16 and ABB Drives profile
reference value 2 (alternative)
6 ACTUAL
VALUE 2
INT16 RO Transparent 16 and ABB Drives profile
actual value 2 (alternative)
2001h 0 T32 CW U32 RWW Transparent 32 profile command word
2002h 0 T32 Ref1 INT32 RWW Transparent 32 profile
2003h 0 T32 Ref2 INT32 RWW Transparent 32 profile reference value 1
2004h 0 T32 SW U32 RO Transparent 32 profile reference value 2
2005h 0 T32 Act1 INT32 RO Transparent 32 profile actual value 1
2006h 0 T32 Act2 INT32 RO Transparent 32 profile actual value 2
2051h 0 T16 CW U6 RWW Transparent 16 profile command word
2052h 0 T16 Ref1 INT16 RWW Transparent 16 profile reference value 1
2053h 0 T16 Ref2 INT16 RWW Transparent 16 profile reference value 2
2054h 0 T16 SW U6 RO Transparent 16 profile status word
2055h 0 T16 Act1 INT16 RO Transparent 16 profile actual value 1
2056h 0 T16 Act2 INT16 RO Transparent 16 profile actual value 2
2100h 0 Number Of
Entries
U8 RO Maximum sub-index in the object
1U6ROAlarm code 1
2U6ROAlarm code 2
3U6ROAlarm code 3
4U6ROAlarm code 4
5U6ROAlarm code 5
2101h 0 ABB CW U6 RWW ABB Drives profile command word
2102h 0 ABB Ref1 INT16 RWW ABB Drives profile reference value 1
2103h 0 ABB Ref2 INT16 RWW ABB Drives profile reference value 2
2104h 0 ABB SW U6 RO ABB Drives profile status word
2105h 0 ABB Act1 INT16 RO ABB Drives profile actual value 1
2106h 0 ABB Act2 INT16 RO ABB Drives profile actual value 2
