4.4.3 Changing the oil in axis-2 gearbox
Location of the gearbox and oil plugs
The gearbox and its oil plugs are located as shown in the figure.
xx2100002087
Oil plug with nipple for draining and filling with an oil dispenserA
Oil plug hole for ventilation and inspectionB
Option Inverted (3317-1)
xx2100002088
Oil plug with nipple for draining and filling with an oil dispenserA
Oil plug hole for ventilation and inspectionB
