10 Drag the rectangle so it covers the pattern.
xx1900000960
11 Click Edit to open the corresponding model creating window. For detail
procedures on how to create a geometric model or a blob model, see
Configuring a geometric model with PatMax on page 246, Configuring blob
models on page 257, Histogram on page 272 and Caliper on page 277.
xx1900000961
Continues on next page
