Abbott VP 2000 - Mainframe Tests and Setup Procedures

Section 5 Manually Controlling the Basin Heaters
Abbott VP 2000™ Processor Service Manual 5-37
30-608308/R1—September 2008
Mainframe Tests and Setup Procedures
Application
This test specification applies to the following mainframe
assemblies:
• DS (Double Sided): 117V, 100V, 230V
• DS mainframes assembled for use with the Heater Module
instead of an MS Carrier in 117V, 100V, and 230V
configurations will require a “Test Control Module
Assembly” to be installed for mainframe testing. At the
conclusion of the test, these parts are to be removed.
• The mainframe test and setup check list supplies with each
unit will identify the SN, input voltage and PROM version
for the unit.
Equipment
• Slide Stainer Mainframe: UUT
• Computer with Serial Port
• Serial Printer
• 115/220V Adapter (where applicable)
• Test Control Module (where applicable)
• Fluid Input Hose
• Multimeter
• Variac (where applicable)
• Mainframe Test and Setup Checklist
