Section 4 Pre-Installation Checklist
Abbott VP 2000™ Processor Service Manual 4-9
30-608308/R1—September 2008
Pre-Installation Checklist
Account Information
Site Specifications
Account Name
Delivery Address Bldg. & Floor
City State/Country Zip Code
Primary Contact Phone
Secondary Contact Phone
Customer Number Customer E-mail
Instrument space meets specification criteria
Record space
measurements _____________ Length
_____________ Height
_____________ Depth
Specifications 88.9 cm (35 in) instrument Length
55.9 cm (22 in) total Height
61.0 cm (24 in) total Width
Is instrument blocking a thoroughfare? ___ Yes ___ No
Will an operator using the instrument block a
thoroughfare?
___ Yes ___ No
Is the space provided for commodities inadequate? ___ Yes ___ No
If any of the answers above were YES, consult with the customer on an alternate installation location.
Action plan to resolve:
Weight 100 VAC Unit: 63.5 kg (140 lbs)
117 VAC Unit: 57.6 kg (127 lbs)
230 VAC Unit: 63.5 kg (140 lbs)
System Control Center space meets specification criteria
Record space measurements: ____________ Length ____________ Height ____________ Depth
Specifications: PC (CPU/Monitor/Keyboard): 28 in deep x 28 in wide
Printer (optional): 8 in deep x 16 in wide
Charcoal Filter System with Blower Fan (optional): 18 in deep x 18 in wide
