Section 7 Y-Sensor Board Assembly
Abbott VP 2000™ Processor Service Manual 7-31
30-608308/R1—September 2008
Y-Sensor Board Assembly
Prior to disassembly, move the Robotic Arm to the far end of
the unit away from the Drying Station and leave it in the up
position.
WARNI NG: Always disconnect the system power at the
plug to the wall socket before beginning disassembly of
the unit.
Figure 7.14: Y-Sensor Board Assembly
