Abbott VP 2000 - Water Bath Data; Drying Station; Performance Data

Technical Data Section 3
3-28 Abbott VP 2000™ Processor Service Manual
30-608308//R1—September 2008
Water Bath Data
Drying Station
Table 3.6: Drying Station
Performance Data
Table 3.7: Performance Data
Table 3.5: Water Bath Conditions
Description Specification
Input Line Pressure 10 to 100 psi
Water Type Deionized
Flow Thru Rate Factory set via regulator
approximately 1 liter/min
Recirculation Rate Approximately 3.5 liters/min
Water Bath Capacity Approximately 1,750 ml
Water In Line 3/8 inch reinforced flexible tubing
to fit standard laboratory water tap.
Adapter required for other taps.
Drain Line 1/2 inch flexible tubing gravity feed.
The entire line must be below the
water level in the unit.
Description Specification
Temperature Adjustable 25
o
C to 80
o
C
Description Specification
Slide Capacity 50
Unheated Reagent Vessels 12
Heated Reagent Vessels 3
Water Bath 1
Drying Station 1
Reagent Basin Protocol Volume to Cover Slide 600 ml
Reagent Basin Protocol Volume to Cover Sample 470 ml
Heated Reagent Temperature Adjustment Basin 1: Ambient to 80
o
C
Basin 2: Ambient to 80
o
C
Basin 3: Ambient to 40
o
C
