Abbott VP 2000 - Test Control Module Lights All Eights, Arm Does Not

Troubleshooting Section 6
6-24 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Figure 6.4: Control Module Lights All Eights, Arm Does Not
Move
TEST CONTROL MODULE LIGHTS ALL EIGHTS
ARM DOES NOT MOVE
CHECK THAT HOODS ARE
CLOSED & ACTIVATING
INTERLOCK SWITCHES
PASS FAIL
CLOSE HOODS AND/OR READJUST
INTERLOCK SWITCHES
TEST INTERLOCK SWITCH
PASS FAIL
TEST ROTATION MOTOR
PASS FAIL
REALIGN & PLUG IN
COMPUTER BOARD
TEST BY SUBSTITUTION
POWER SUPPLY BOARD
TEST BY SUBSTITUTION
REPLACE INTERLOCK SWITCH
TEST CONTROL MODULE
TEST BY SUBSTITUTION
1
2
3
3
3
