Repair, Replacement of Spare Parts Section 7
7-24 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Installation
CAUTION: On the interior side of the X/Y Table there
is a metal tab (the X-Position Flag) that engages the
sensors on the X-Sensor Board. When replacing the
X-Sensor Board take care not to damage the flag or
sensors when sliding the board into position. It is
important that the X/Y Table be to the far right.
CAUTION: When installing the drive belt on the motor
and idler pulleys, make sure the drive belt is not
twisted.
CAUTION: Before sliding the Top Cover back into
position, make sure all wiring, cables and connectors
are replaced snugly, within the unit and not hanging
out where they might be sheared off when replacing
the cover.
1. Push the X/Y Table Assembly to the fan end of the unit.
2. Carefully slide the X-Sensor Board Assembly between the
X/Y Table Assembly and the Drive Plate.
3. Reassemble by following the removal procedure in reverse.
