Troubleshooting Section 6
6-10 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Symptoms and Faults
The following is a partial list of problems that may occur and
modules that could contain the cause. Modules are listed in
likelihood of being the cause of the symptom.
Table 6.1:
Symptom and Faults
Fault Check/Replace
No power when unit is first turned ON. • Power Switch/Breaker
•Line cord
• Power Supply Plug-in
• Fuse - 230V unit
•External power
Power stays ON with switch OFF Power Switch/Breaker
Circuit Breaker trips • Power Supply
• Power Switch/Breaker
•Line cord
• Line filter
Exhaust Fan operates but no other power
comes ON
Power Supply
Exhaust Fan does not operate • Fan
•Cable to Fan
• Power Supply
No X-movement of Robotic Arm • Check Interlock Switches
• Physical obstructions
• X-drive Belt (shipping strap)
•Tension Arm Spring
• X-motor Assembly
• Power Supply
•Computer Control Board
No rotational movement of Robotic Arm • Robotic Arm
•Computer Control Board
