Abbott VP 2000 - Component Information

Troubleshooting Section 6
6-12 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Component Information
Dryer Fan does not operate • Power Supply
•Computer Control Board
•Fan
Table 6.2:
Component Information
Resistance Cartridge Heater Basin 1 ~ 100 ohms
Resistance Cartridge Heater Basin 2 ~ 100 ohms
Resistance Cartridge Heater Basin 3 ~ 300 ohms
Dielectric Strength 1000V
Dryer Element Resistance 41 ohms
Dryer Temperature = [(Voltage Across R18)
*200]
273
o
C
Fan Resistance ~ 33 ohms (DC)
Pump Resistance ~ 24 ohms (DC)
Solenoid Resistance ~ 133 ohms (DC)
Stepper Motor X 72 ohms / 36 ohms Split
Stepper Motor Y 72 ohms / 36 ohms Split
Table 6.1:
Symptom and Faults
Fault Check/Replace
