Troubleshooting Section 6
6-38 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Fluid Will Not Fill Rinse Tank: Fault 15.0
1. Power ON.
WARNING: Electrical Shock Hazard. Solenoid will
make a clicking sound when “flow” button is turned
ON and OFF.
2. Power OFF, top cover, center cover and AC power barrier
removed.
Check that all plug-in connectors [J1, J2, J3, J7, J8, J9, J10,
J11, J12, J13 and J18] are correctly aligned and fully
seated. A disconnect at J18 will prevent the solenoid from
operating.
Power ON.
WARNING: Electrical Shock Hazard. With J18
unplugged, check for 120V AC between Pins 2 and 3
when Robotic Arm is in Bath 2 in the down position,
and “recirculate” button is activated.
3. Power ON. Center cover and AC power barrier removed.
WARNING: Electrical Shock Hazard. Disengage the
yellow locking ring on the regulator by pulling up. Turn
regulator knob clockwise or counter-clockwise to
increase or decrease the water flow.
4. Replace Fluid-In Control Assembly according to Section 8,
Repair/Replacement of Spare Parts.
5. Power OFF, top cover removed.
Test by substituting known good units for power supply
board and computer board.
