Section 8 Packing
Abbott VP 2000™ Processor Service Manual 8-9
30-608308/R1—September 2008
Packing
1. Place the unit onto the shipping container base.
2. Place the Vessel Carrier with cover on the unit.
3. Slide the shipping container sleeve into position.
4. Insert hoods into the hood cartons.
5. Wrap slide basket, basket tool, interface cable and power
cable and insert them in one of the hood cartons.
6. Install the lid and strap or tie container together.
Figure 8.1: Instrument and Hood Packing Box
Instrument Packed
Hood Packed
Hoods and Instrument Packed
