Installation Section 4
4-12 Abbott VP 2000™ Proceessor Service Manual
30-608308/R1—September 2008
Instrument Installation
Instrument installation involves the following activities:
• Unpacking the instrument
• Placing the instrument on the lab bench
• Unpacking the accessories
• Installing the Abbott VP 2000 Processor
• Installing the PC, Printer, and Charcoal Filter System
• Installing the UPS
• Installation the System Software
•Conduct System QC
Unpacking the Instrument
1. Remove the bands, cardboard top, and box from around
the instrument.
2. Open the two boxes that are enclosed and unwrap the
front and back transparent hoods; set them aside to
attache to the unit later.
3. Dismantle the rest of the shipping crate.
Location
Place the instrument at the desired (pre-determined) location.
CAUTION: Two people will be required to lift and
move the Abbott VP 2000 Processor to the desired
location.
• Protect from drafts and direct sunlight.
• Provide enough room for the Abbott VP 2000 Processor
and PC.
• Ensure that the transparent safety hoods on each side of
the Abbott VP 2000 Processor can be easily opened
without obstruction.
• Bench-top or table-top should be capable of supporting
the unit’s 57.6 kg (127 lbs) weight for the 117 VAC model
or 63.5 kg (140 lbs) weight for the 100 VAC and 230 VAC
models as well as that of the PC.
