Section 7 Pump Assembly
Abbott VP 2000™ Processor Service Manual 7-9
30-608308/R1—September 2008
Removal
1. Remove the Hoods by gently squeezing inward on the two
(2) metal arms that connect the Hood to the unit. Remove
the Carrier Tray Assembly.
2. Remove the Drip Tray, located in the lower center of the
unit, by grasping the flange on the tray from the rear of
the unit and lifting upward and out.
3. Remove the AC Power Barrier. Loosen three (3) 6-32 x 1/4
Phillips-Head screws located at the ends of the Barrier, and
slide the barrier back and up to remove.
4. Unplug the pump connector at the System Harness
Shroud.
5. Disconnect the green Pump Ground Wire by removing the
6-32 hex nut securing the wire to the base pan.
6. Remove the flexible tubing from the pump input and
output barbed fitting.
7. Remove two (2) 6-32 x 1/4 Phillips-Head screws fastening
the Pump Assembly to the pan. Remove the Pump
Assembly.
Installation
Reassemble by following the removal procedure in reverse.
NOTE: When reinstalling the flexible tubing, moisten
the inside diameter of the tube to ease installation.
Ensure that the tubing is fully seated on it barbed
fitting.
