Repair, Replacement of Spare Parts Section 7
7-32 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Removal
1. Remove the hoods by gently squeezing inward on the two
(2) metal arms that connect the hoods to the unit.
2. Remove the Top Cover by unscrewing six (6) 6-32 x 1/4
Phillips-Head screws, three (3) on each side.
3. Remove the three (3) connectors plugged into the
Y-Sensor Board at J1, J2 and J3.
4. Remove the Y-Sensor Board by unscrewing the four (4)
6-32 x 1/4 Phillips-Head screws that secure the board to
the Y-Motor Mounting bracket.
Installation
Reassembly by following the removal procedure in reverse.
CAUTION: Before sliding the Top Cover back into
position, make sure all wiring, cables and connectors
are replaced snugly, within the unit and not hanging
out where they might be sheared off when replacing
the cover.
