Abbott VP 2000 - Technical Data and Requirements

Section 3 Technical Data and Requirements
Abbott VP 2000™ Processor Service Manual 3-27
30-608308/R1—September 2008
Technical Data and Requirements
Dimensions and Weight
Electrical Supply
Table 3.3: Instrument Dimensions
Description Specification
Length 88.9 cm/35 in
Height 55.9 cm/22 in
Width 61.0 cm/ 24 in
Weight 117 VAC Unit: 57.6 kg/127 lbs
230 VAC Unit: 63.5 kg/140 lbs
Table 3.4:
Electrical Supply
Description Specification
Voltage PN 30-102832
117 VAC Nominal (108-126) 60 Hz
PN 30-102833
230 VAC Nominal (207-258) 50/60 Hz
Circuit Breaker ON/OFF
Switch
PN 30-102832: 6 Amps
30-102833: 4 Amps
