Section 4 Instrument Installation
Abbott VP 2000™ Processor Service Manual 4-19
30-608308/R1—September 2008
4. Plug the cord into the Filter System and into the power
source.
CAUTION: Connect the power cord into a grounded
socket. Use the power cord supplies with the unit, no
other power cord is approved for use with this
equipment.
Connecting the Power
Figure 4.2: Power Cord to Port A
1. Place the power switch on the front of the unit in the OFF
position.
2. Plug the power cord into port A.
3. Plug the other end of the power cord into a grounded
outlet with appropriate voltage.
A
