Repair, Replacement of Spare Parts Section 7
7-26 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Removal
1. Remove the Hoods by gently squeezing inward on the two
(2) metal arms that connect the hoods to the unit.
2. Remove the Top Cover by unscrewing six (6) 6-32 x 1/4
Phillips-Head screws, three (3) on each side of the unit.
3. On the Power Supply, unplug the two (2) connectors at
location P101 and P102.
4. Remove the Power Supply Assembly by removing the four
(4) 6-32 x 3/8 Phillips-Head screws that connect the
Assembly to the Drive Plate.
Installation
Reassembly by following the removal procedure in reverse.
CAUTION: Before sliding the Top Cover back into
position, make sure all wiring, cables and connectors
are replaced snugly, within the unit and not hanging
out where they might be sheared off when replacing
the cover.
