Repair, Replacement of Spare Parts Section 7
7-34 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Removal
1. Remove the hoods by gently squeezing inward on the two
(2) metal arms that connect the hoods to the unit.
2. Remove the Top Cover by unscrewing six (6) 6-32 x 1/4
Phillips-Head screws, three (3) on each side.
3. Unplug the cable from the Y-Motor Assembly at J1 on the
Y-Sensor Board.
4. Remove the four (4) 6-32 x 3/4 Phillips-Head screws that
fasten the Y-Motor Assembly to the Y-Motor bracket, and
remove the Assembly.
Installation
Reassemble by following the removal procedure in reverse.
CAUTION: Before sliding the Top Cover back into
position, make sure all wiring, cables and connectors
are replaced snugly, within the unit and not hanging
out where they might be sheared off when replacing
the cover.
