Section 5 Visual Inspection
Abbott VP 2000™ Processor Service Manual 5-51
30-608308/R1—September 2008
Visual Inspection
1. Check that the screw used to secure the pulley on the
X-Drive Motor is on the flat of the motor shaft.
Check off the following block on the checklist:
X MOTOR MOUNTING SCREW
2. Check that the cable on the Y-Table is free to move
Up/Down as the table moves.
Check off the following block on the checklist:
Y TABLE WIRE
