Abbott VP 2000 - No Air Movement in Dryer: Fault 18.0

Section 6 Maintenance Diagnostic Faults
Abbott VP 2000™ Processor Service Manual 6-43
30-608308/R1—September 2008
No Air Movement in Dryer: Fault 18.0
1. Power OFF, top cover, center cover, and AC power barrier
removed.
Check that connectors J7 and J10 [power supply board[
and J14 [fan connector] are correctly aligned and fully
seated.
2. Power OFF, top cover, center cover, and AC power barrier
removed.
Disconnect J14/P14 [fan connectors]. Check resistance of
fan motor. Pins 1 and 2 of P14 on fan connector should
be approximately 69 .
3. Power ON, top cover, center cover, and AC power barrier
removed.
WARNING: Electrical Shock Hazard. From keypad,
move Robotic Arm to Bath 1 and down into dryer.
Check for 120V AC between J14, Pins 1 and 2 [harness
fan connector].
4. Test by substituting known good unit for power supply
board.
