Troubleshooting Section 6
6-44 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Figure 6.17: No Air Movement in Dryer
NO AIR MOVEMENT IN DRYER
INSPECT CONNECTORS
1
REALIGN & PLUG IN
PASS FAIL
CHECK FAN MOTOR
PASS FAIL
REPLACE FAN
ASSEMBLY
CHECK VOLTAGE
FAIL
POWER SUPPLY BOARD
TEST BY SUBSTITUTION
2
2
4
