No Rotation Movement: Fault 3.0
1. Power OFF, top cover removed.
Check that all plug-in connectors [J1, J2, J3, J7, J8, J9, J10,
J11, J12 and J13] are correctly aligned and fully seated.
A disconnect at J1 and j3 will prevent all movement in
the Y direction.
A disconnect at the other connections may prevent
rotation movement under certain conditions.
2. Double-sided unit:
Check that the carriers installed in the front and rear of
the system are the same type, i.e., 600 ml or 1200 ml.
All units:
Review the program to confirm that the bath positions
are valid for the type of carriers installed.
• Example: A single-sided HMS/MS-100 has a total of six
(6) bath positions - a program directing the Robotic
Arm to go to bath eight (8) would be invalid.
• Example: A double-sided HMS/DC-50 has a total of 22
bath positions, but a unit with an MS-50 carrier in the
front and DS-100 carrier in the rear would have a total
of 14 vessels - a program directing the Robotic Arm to
go to bath 16 would be invalid.
3. Power ON, top cover removed.
WARNING: Electrical Shock Hazard. Test the rotation
sensors according to the sensor test program defined in
this section.
