Troubleshooting Section 6
6-20 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
Figure 6.3: No Y Movement
NO Y MOVEMENT
INSPECT Y DRIVE BELT
1
PASS FAIL
REPAIR OR REPLACE
INSPECT Y MECHANICAL
MOTION
2
PASS FAIL
INSPECT CONNECTORS
FAILPASS
TEST FAIL SAFE FEATURE
PASS FAIL
TEST Y MOTOR
FAILPASS
REALIGN & PLUG IN
REPLACE ROBOTIC ARM
REPLACE Y MOTOR
COMPUTER BOARD
7
TEST BY SUBSTITUTION
POWER SUPPLY
BOARD
TEST BY SUBSTITUTION
7
TEST CONTROL
MODULE
TEST BY SUBSTITUTION
7
REPAIR OR REPLACE
3
4
5
TEST Y SENSORS
PASS FAIL
REPLACE Y SENSOR BOARD
6
