Technical Data Section 3
3-12 Abbott VP 2000™ Processor Service Manual
30-608308//R1—September 2008
Mechanical Design
NOTE: For purposed of consistent terminology, the
terms Front, Back, Left, and Right as they refer to the
unit are used throughout this manual:
• Front: defined as the side of the unit containing the
Wash Bath and Drying Station
• Back: defined as the side opposite the Front
• Left: defined as the side with the Power Switch
• Right: defined as the side with the Exhaust Fan
As a reminder of the special meaning of these terms, they are
capitalized when used in the specific way defined above.
Figure 3.3: Abbott VP 2000 Processor
