Section 6 Maintenance Diagnostic Faults
Abbott VP 2000™ Processor Service Manual 6-39
30-608308/R1—September 2008
Figure 6.14: Fluid Will Not Fill Rinse Tank
FLUID WILL NOT FILL RINSE TANK
FLUID LINE HOOKED UP TO
WATER SUPPLY
WATER SUPPLY ON!
ACTIVATE FLOW BUTTON
(RED LIGHT WILL GO ON)
FLOW BUTTON ON
(DISPLAY PANEL)
ROBOTIC ARM IN BATH 2 & DOWN
CONNECT FLUID LINE TO SOURCE
CHECK FLUID LINES FOR KINKS &
BLOCKAGES
MOVE TO BATH 2 & DOWN
REALIGN & PLUG IN
YES NO
YES NO
YES NO
YES NO
COMPUTER BOARD
TEST BY SUBSTITUTION
POWER SUPPLY BOARD
TEST BY SUBSTITUTION
REPLACE FLUID-IN CONTROL
ASSY
WATER FLOWING INTO TANK
NO YES
CHECK FOR PROPER
INSTALLATION OF STANDPIPE
SOLENOID FUNCTIONING
YES NO
REGULATOR SET PROPERLY
NO
CHECK CONNECTORS
PASSYES
1
3
FAIL
2
READJUST
4
5
5
REPLACE CONTROL
MODULE
