Installation Section 4
4-10 Abbott VP 2000™ Proceessor Service Manual
30-608308/R1—September 2008
Delivery Route
Power Requirements
Page 2 of 3
Measure door width openings from entryway to lab and record here: _________________________________
Check one: _____ Door and entryway openings are 76.2 cm (30 in) or wider
_____ Door and entryway openings are less than 63.5 cm (25 in)
_____ Door and entryway openings are less than 61 cm (24 in). Contact area customer service.
Measure turning radius in passageways. The Abbott VP 2000 Processor requires a combined 114 cm (45 in) of width of both
passageways around corners.
Is there a loading dock? Yes _____ No _____ If No, contact area customer service
Does the loading dock have a raised delivery platform? Yes _____ No _____ If No, contact area customer service
If any of the following are answered YES, contact area customer service
Does the instrument have to be moved up or down stairs? Yes _____ # of flights __________ No _____
Does the instrument have to be moved via freight elevator? Yes _____ Elevator door width __________ No _____
Will the instrument have to be lifted over any barriers? Yes _____ Height of barrier __________ No _____
Resolution plan (if necessary):
Dedicated/Isolated 15 amp power line with circuit breaker identified as Abbott VP 2000 Processor is optimal. If not possible,
how clean is the power? What other equipment is plugged into the same power line? See Uninterruptible Power Supply below.
Abbott VP 2000 Processor power outlet is within 182 cm (6 ft) of the instrument’s electrical input panel.
Power Measurements
System Requirements:
NOTE—All system components
will run at the single phase voltage
standard for the country (e.g.
Japan 100VAC +
10%, US 110VAC
+ 10%, EU 220VAC + 10%)
Voltage range: 100 VAC (90 - 110)
117 VAC (108 - 126)
230 VAC (207 - 258)
Voltage frequency: 100 VAC: 50/60 Hz
117 VAC: 60 Hz
230 VAC: 50/60 Hz
Power: 1200 VA
Circuit breaker: 100 VAC: 7 Amps
117 VAC: 6 Amps
230 VAC: 4 Amps
Line Noise: Breaker Closed Open
Line to neutral ??? ???
Line to earth ??? ???
Neutral to earth ??? ???
NOTE—If the power is not within specification, have the customer notify their electrician for correction
Four (4) outlets provided (instrument, computer, printer, and monitor) _______ Yes _______ No
NOTE—If four outlets are not available, have the customer notify their electrician to add additional outlets
