Section 5 Electrical Test
Abbott VP 2000™ Processor Service Manual 5-41
30-608308/R1—September 2008
14. Push “TEST” - “RUN” - “1” - “ENTER”. A built-in test will
start. When the arm moves past Bath 2, place the power
switch in the OFF position. The power interrupt alarm
should continue to sound. The arm will return to Bath 1.
Push “CLEAR” and the power interrupt alarm should go
OFF.
Check off the following block on the checklist:
 POWER INTERRUPT ALARM
15. Place the UUT power switch in the ON position. When the
control panel displays “READY” press “TEST” - “ENTER”
keys. Next, press the following keys and observe the
number symbol that appears in the Bath display. Verify
each number.
Table 5.4:
Bath Display Number Symbols
Key Number
PROG 13
REVIEW 20
PAUSE 16
RUN 14
AGITATE 19
PRINT 15
ABORT 21
UP ARROW 22
LEFT ARROW 25
RIGHT ARROW 24
DOWN ARROW 23
11
44
77
CLEAR 12
22
