Figure 6.8: Robotic Arm Does Not Follow Program or Manual
Command
ROBOTIC ARM DOES NOT FOLLOW PROGRAM OR MANUAL COMMAND
CHECK FOR PROPER
CARRIER CONFIGURATION
PASS FAIL
INSTALL CORRECT CARRIERS
REALIGN PLUG IN
INSPECT CONNECTORS
PASS FAIL
1
2
COMPUTER BOARD
TEST BY SUBSTITUTION
TEST CONTROL MODULE
TEST BY SUBSTITUTION
3
4
