Section 3 Application and Features
Abbott VP 2000™ Processor Service Manual 3-9
30-608308/R1—September 2008
Table 3.2: Abbott VP 2000 Processor Components Rear View
Component Description
Staining Vessels (12) Plastic Reagent Vessels
Back Interlock Switch Interlock Switches on the unit stops all
operation, except the heated basin
temperature controls, when a hood is raised
Drive Pulley Mounted on the X-Motor shaft.
X-Drive Belt Toothed belt that interlocks on the Drive
Pulley and Idler Pulley.
X-Sensor Board X-Sensor Board has photosensors that
determine the X/Y Table location and
provides inputs to the Computer Control
Board.
Drive Plate Hold the X-Sensor Board, X-Motor, Idler
Pulley and Rails for the X/Y Table rollers.
X/Y Table with Y-Motor and
Y-Sensor Board
X/Y Table moves up and down with the
Robotic Arm mounted. Provides inputs to
the Computer Control Board and operates
in a normal movement or in an “agitate”
operation.
Idler Pulley/Tension Spring Far Side Maintains X-Belt tension during movement.
Drive Rails Drive Rails are mounted on the Drive Plate.
Provide a mounting area for the X/Y Table.
