18 - External units
You can dene up to four recipients
and congure emails for up to ten dif-
ferent sensor types. The recipients are
the same for all external unit emails.
Click on an email row to display the
Edit email dialog. Select the device
type and the frequency.
You can specify a start time, a day of the week or a date in the month.
The example below shows an email containing a single Z-D-OUT module (like the one in the exam-
ple in 18.3).
There is a header containing the module name and module address. The second row contains the
last twelve characters of the MAC address, which uniquely identies the device. The third row con-
tains the number 10, the name of the sensor type and the ID number of the type denition.
The row beginning 000 contains the table headings separated by tabs. Units appear in brackets. The
next row contains values for each unit of the specied type. There is only one row in this example. It
starts with 002 because the external unit is number 2. The values are also tab-separated, making it
easier to import the email into database applications or Excel.
Module name, Module address
00-30-5E-03-00-FC
10, Seneca Z-D-OUT 21002
000 Name Last update Status DO1 (-) DO2 (-) DO3 (-) DO4 (-) DO5 (-)
002 Dout 2006-03-21 18:00:13 (OK) 0 1 1 0 0
