A - Technical data
A�3 Outputs
A�3�1 Analog out
Quantity: 8
Output signal: 0-10 V
Resolution: 8 bit
Max current: 2mA
A�3�2 3� Digital out
Quantity: 8
Output: Open collector
Max current: 0.5A
Max voltage: 36 VDC
Protection: Short circuit proof, protected from excessive temperatures and transients
A�4 Communication
A�4�1 Protocols
Protocols: InterNische TCP/IP stack: TCP, IP, UDP, ARP, SLIP, ICMP, TFTP
Web server: HTML, CGI, SSI, SSP
PPP: CHAP, PAP, VJ compression, FTP
Email: SMTP
A�4�2 Ethernet
Speed: 10 Mbit/s
Standard: IEC 802.3
Connector: RJ45 TP (twisted pair)
Cable: Cat5
Max length: 100 m
A�4�3 RS 232
Quantity: 1
Speed: Congurable 1.2-38.4 kbps
Handshake: DTR, RTS, CTS
Connector: 9-pol Dsub male
Max cable length: 15 m (9600 bps)
