Setting: HDD
52
Mode: Quota
In this mode, video data is divided between the total
number of data storage devices connected and written
onto them.
Camera
Selection of the camera channel
to be processed
Used Video
Capacity
Video storage space currently in
use on the linked data storage
devices.
Used Picture
Capacity
Picture storage space currently
in use on the linked data storage
devices.
HDD Capacity
(GB)
Total available hard disk drive
capacity (in GB).
Max. Record
Capacity (GB)
Specify the maximum video
recording size on the linked
data storage devices for each
camera.
Enable HDD
Sleeping
When this function is activated,
idle hard disk drives go into
standby mode.
1. Use Copy to specify if the setting is to be applied to
all cameras.
2. Confirm the settings by clicking on Apply and exit the
menu by clicking on OK.
3. Click on Apply and confirm the reboot in the next
window by clicking on OK.
Mode: Group
In this mode, video data can be specifically (and also
redundantly) stored on selected data storage devices.
Here, the storage devices are organised into “groups”.
A group must include at least one HDD.
Parameter
Setting
Record on HDD
Group
Select HDD group
Camera
Select which cameras should be
stored in the group currently
selected.
Enable HDD
Sleeping
When this function is activated,
idle hard disk drives go into
standby mode.
The HDD groups are configured in the General menu.
To do this, click on to open the HDD group settings.
Parameter
Description
HDD No.
Internal hard disk drive number
for the recorder.
R/W
In this mode, video data is
written onto the data storage
device and can also be read
(default setting).
