Adixen ASM GRAPH D+

To Next Page

To Previous Page

D 400

Symptoms

description

ASM 142 - 142 D - Graph D+ GB 03978 - Edition 01 - January 2009

SYMPTOM

ORIGIN

DIAGNOSTIC

CONFIRMATION

REMEDY

No cell

pressure

display Filament

OFF

requested

Short circuit on triode

electrode

n Check

filament

status in SPECTRO -

n Eliminate the short circuit in

the

cell

6/6
