BZ001M056A ADT‐DK300A/400A Engraving Machine
110
parameters,andthefinallydisplayednumberwillbeeffective.
¾ This parameter requires restart to take effect; the corresponding
axismustberotaryandsetto360°display(P2.062~069);
045
XphysialAssignNum(re start)
046
YphysialAssignNum(restart)
047
ZphysialAssignNum(restart)
048
4physialAssignNum(restart)
Range : 0~4
Unit : PulseportsequenceNo.
Authority : SuperAdmin
Default :
Effectivetime : Restart
Note : Indefaultmode,theactualnumberofeveryaxiscorrespondstothesilk
screennumberontheshell.Ifcertainfunctionaxisisabnormal,youcan
replace the axis through
this function. For example, set P2.045 to 4,
P2.048to1,then,anyoperationtoXaxiswillbetheoperationtoAaxis
encoderportontheshell.
0:nosuchaxis
1~4:correspondingto1#‐4#axis
049 SpindlephysialAssignNum(restart)
Range : 0~4
Unit : PulseportsequenceNo.
Authority : SuperAdmin
Default :
Effectivetime : Restart
Note : It is set to 0 by default, indicating that the principal axis is in variable
frequency control mode, i.e. analog or gear position control mode. To
use servo principal axis,
a coding port is required (servo principal axis
must be in position control mode); you can modify this parameter to
specifythefunction.
0:variablefrequencyprincipalaxisadjustedbyanalog
1~4:correspondingto1#‐4#axis
Note:Ifapulseportisspecifiedasthefunctionportofprincipal
axis,the
pulse port should be removed from previously corresponding function
axis number, or else the system will assign to principal axis after
restartedandtheoriginalfunctionaxiswillbeinvalid.
