61200600L1-1A © 2002 ADTRAN, Inc. 163
Total Access 600R System Manual Section 5 DLP-010
11. After an appropriate length of time, the user may Telnet back into the unit.
Loading Configuration using TFTP Server Accessible Across the WAN
1. Telnet into the unit using FULL or SUPPORT levels (refer to DLP-003, Adding/Removing Telnet Users
and Changing Password Security Levels).
2. Verify the TFTP server is running on the network.
Verify that the unit can ping the TFTP server.
3. Go to the S
YSTEM UTILITY menu and select the CONFIGURATION TRANSFER menu; then press <Enter>.
4. Verify the T
RANSFER METHOD is set to TFTP.
5. Set the TFTP S
ERVER IP ADDRESS to the IP address of the machine running the TFTP Server
Program.
6. Change TFTP S
ERVER FILENAME to a unique filename including path. This will be the name of the
configuration file retrieved from the remote server. An example filename would be ta_iad.cfg.
Some TFTP servers constrain the format of the filename depending on the operating system of the
server. For example, a TFTP server running on a PC under Windows 3.1 may only permit 8.3 format
filenames (8 characters, period and three extension characters).
7. Select the LOAD AND USE CONFIG menu field and press <Enter>.
Enter Y to confirm the request.
8. View CURRENT TRANSFER STATUS to verify the progress of the current upload.
9. When the upload has successfully completed, I
DLE displays in the CURRENT TRANSFER STATUS field.
TFTP is not secure. No passwords are required for client access. Anyone can access files
through the IP port on the server machine if they know the target file’s name.
If you are using the ADTRAN TFTP server, the IP address displays in the STATUS field.
For other TFTP servers, please refer to the appropriate documentation.
The unit is rebooted immediately after a configuration is successfully loaded. Any online
sessions will be terminated.
