Section 5 DLP-012 Total Access 600R System Manual
168 © 2002 ADTRAN, Inc. 61200600L1-1A
DLP-012
Perform Steps Below in the Order Listed
1. Connect to the unit using the RJ-45 CRAFT interface.
If you are not already connected to the unit’s CRAFT interface (either with a
VT100 compatible terminal or with a PC running VT100 emulation software), follow the procedure in
DLP-001, Connecting the Terminal or PC to the CRAFT Port. Connecting to the
CRAFT interface
limits the config transfer procedure to XMODEM Only.
2. Log in to the unit. (See DLP-002, Logging in to the System, for details.)
3. Go to the S
YSTEM UTILITY menu and select CONFIGURATION TRANSFER menu; press <Enter>
4. Set the T
RANSFER METHOD menu to XMODEM.
5. Select L
OAD AND USE CONFIG to start the transfer. Enter Y to confirm the transfer and prepare the unit
for the transfer download.
When the unit is ready to receive the XMODEM configuration file, the menu screen will clear and
display XMODEM/CRC: Transmit CONFIG file now... If this does not appear, please review the
steps above for possible configuration errors.
6. From the terminal emulation software, begin the XMODEM transfer by using the appropriate command
sequence. For Windows HyperTerminal, select T
RANSFER>SEND FILE. Enter the filename (including
path) and select XMODEM as the T
RANSFER METHOD. Configuration files should have a .cfg extension.
If necessary, refer to the terminal emulation software documentation for help.
Because XMODEM data is being transferred in-band through the menu interface, the VT100 menus of
the unit will be inoperable from the
CRAFT interface. You can cancel the update at any time within the
terminal emulation software. (Please consult the documentation provided by the terminal emulation
software to determine how to do this.)
7. After the config transfer is complete, the CONFIG TRANSFER menu will be displayed.
Follow-up Procedures
Once this procedure is complete, return to the procedure which referred you to this DLP and continue with
the tasks indicated there.
The following message is displayed: “Warning: WAN link may be reset after transfer
complete!”
