MANAGING SWITCH
117
PoE Port Settings
The PoE Port Settings page allows you to configure the port status, its power limitations,
legacy mode status, and power limit settings.
To access this page, click Management > Power Over Ethernet > PoE Port Settings.
Figure 4-90. Management > Power Over Ethernet > PoE Port Settings
The following table describes the items in the previous figure.
The ensuing table for PoE Information settings are informational only: Port, Enable State,
Power Limit From Classification, Priority, Legacy and Power Limit (W).
Table 4-88. Management > Power Over Ethernet > PoE Port Settings
Item Description
Port Click the drop-down menu to select a PoE port.
Enabled Select Enabled or Disabled to designate the PoE port function by ports.
Power Limit From
Classification
Select Enabled or Disabled to designate the power limit classification.
Legacy Mode Select Enabled or Disabled to designate the legacy mode option for the
port.
Priority Click the drop-down menu to configure the power supply priority: Critical,
Low, Medium or High. Default is Low.
Power Limit Enter a number to set the port power current limitation to be given to the
Powered Device (PD)
Apply Click Apply to save the values and update the screen.
