MANAGING SWITCH
36
4.4. System
4.4.1 IP Settings
The IP Settings menu allows you to select a static or DHCP network configuration. The
Static displays the configurable settings for the static option.
To access this page, click System > IP Settings.
Figure 4-9. System > IP Settings
The following table describes the items in the previous figure.
The ensuing table for IP Address Information settings are informational only: DHCP State,
Static IP Address, Static Subnet Mask, Static Gateway, Static DNS Server 1 and Static DNS
Server 2.
Table 4-7. System > IP Settings
Item Description
Mode Click the radio button to select the IP Address Setting mode: Static or
DHCP.
IP Address Enter a value to specify the IP address of the interface. The default is
192.168.1.1.
Subnet Mask Enter a value to specify the IP subnet mask for the interface. The default is
255.255.255.0.
Gateway Enter a value to specify the default gateway for the interface. The default is
192.168.1.254.
DNS Server 1 Enter a value to specify the DNS server 1 for the interface. The default is
168.95.1.1.
DNS Server 2 Enter a value to specify the DNS server 2 for the interface. The default is
168.95.192.1.
Apply Click Apply to save the values and update the screen.
