MANAGING SWITCH
58
4.5.7 802.3az EEE
The 802.3az Energy Efficient Ethernet (EEE) innovative green feature reduces energy
consumption through intelligent functionality:
 Traffic detection — Energy Efficient Ethernet (EEE) compliance
 Inactive link detection
Inactive link detection function automatically reduces power usage when inactive links or
devices are detected.
To access this page, click L2 Switching > 802.3az EEE.
Figure 4-29. L2 Switching > 802.3az EEE
The following table describes the items in the previous figure.
The ensuing table for EEE Enable Status settings are informational only: Port and EEE
State.
Table 4-27. L2 Switching > 802.3az EEE
Item Description
Port Select Enter the port to setup the EEE function.
State Click Enabled or Disabled to set the state mode of the port select setting.
Apply Click Apply to save the values and update the screen.
