Advantech EKI-7428G Series User Manual

MANAGING SWITCH
105
4.8.3 Rate Limit
Rate Limits features control on a per port basis. Bandwidth control is supported for the
following: Ingress Bandwidth Control, Egress Bandwidth Control and Egress Queue.
Ingress Bandwidth Control
The Ingress Bandwidth Control page allows you to configure the bandwidth control for a
listed port.
To access this page, click QoS > Rate Limit > Ingress Bandwidth Control.
Figure 4-77. QoS > Rate Limit > Ingress Bandwidth Control
The following table describes the items in the previous figure.
The ensuing table for Ingress Bandwidth Control Status settings are informational only:
Port and Ingress Rate Limit (Kbps).
Table 4-75. QoS > Rate Limit > Ingress Bandwidth Control
Item Description
Port Enter the port number for the rate limit setup.
State Select Disabled or Enabled to set the port’s state status.
Rate (Kbps) Enter the value in Kbps (16 to 1000000) to set as the bandwidth rate for the
selected port.
Apply Click Apply to save the values and update the screen.
