MANAGING SWITCH
53
The following table describes the items in the previous figure.
Port-VLAN Mapping
To access this page, click L2 Switching > 802.1Q VLAN > Port-VLAN Mapping.
The ensuing table for Port-VLAN Mapping Table settings are informational only: Port,
Mode, Administrative VLANs and Operational VLANs.
4.5.5 Q-in-Q
Q-in-Q is commonly referred as VLAN stacking in which VLANs are nested by adding two
tags to each frame instead of one. Network service provider and users both can use VLANs
and makes it possible to have more than the 4094 separate VLANs allowed by 802.1Q.
There are three ways in which a machine can be connected to a network carrying double-
tagged 802.1ad traffic:
via a untagged port, where both inner and outer VLANs are handled by the switch or
switches (so the attached machine sees ordinary Ethernet frames);
via a single-tagged (tunnel) port, where the outer VLAN only is handled by the switch
(so the attached machine sees single-tagged 802.1Q VLAN frames); or
via a double-tagged (trunk) port, where both inner and outer VLANs are handled by the
attached machine (which sees double-tagged 802.1ad VLAN frames).
Table 4-22. L2 Switching > 802.1Q VLAN > Port to VLAN
Item Description
Port Displays the assigned port to the entry.
Interface VLAN
Mode
Displays the assigned mode to the listed VLAN port.
Hybrid: Port hybrid model.
Access: Port hybrid model.
Trunk: Port hybrid model.
Tunnel: Port hybrid model.
Membership Displays the assigned membership status of the port entry, options include:
Forbidden, Excluded Tagged or Untagged.
Apply Click Apply to save the values and update the screen.
