MANAGING SWITCH
54
Global Settings
The Global Settings page allows you to set the outer VLAN Ethertype setting.
To access this page, click L2 Switching > Q-in-Q > Global Settings.
Figure 4-25. L2 Switching > Q-in-Q > Global Settings
The following table describes the items in the previous figure.
The ensuing table for QinQ Global Information settings are informational only: Outer
VLAN Ethertype.
Table 4-23. L2 Switching > Q-in-Q > Global Settings
Item Description
Outer VLAN
Ethertype
Enter the outer VLAN handled by the switch giving the attached machine a
single-tagged 802.1Q VLAN frame.
Apply Click Apply to save the values and update the screen.
