MANAGING SWITCH
118
PoE Port Status
To access this page, click Management > Power Over Ethernet > PoE Port Status.
The ensuing table for PoE Port Status settings are informational only: Port, Current (mA),
Voltage (V), Power (W) and Temp. (°C).
4.9.4 TCP Modbus
The TCP Modbus function allows for client-server communication between a switch module
(server) and a device in the networking running MODBUS client software (client).
TCP Modbus Settings
The TCP Modbus Settings page allows you to configure the modbus function.
To access this page, click Management > TCP Modbus > TCP Modbus Settings.
Figure 4-91. Management > TCP Modbus > TCP Modbus Settings
The following table describes the items in the previous figure.
The ensuing table for TCP Modbus Status settings are informational only: TCP Modbus
status and TCP Modbus time out.
Table 4-89. Management > TCP Modbus > TCP Modbus Settings
Item Description
State Click Disabled or Enabled to set the TCP Modbus state.
Time out Enter the value (1 to 86400) to define the timeout period between transport
time.
Apply Click Apply to save the values and update the screen.
