Advantech EKI-7428G Series User Manual

MANAGING SWITCH
78
Port Settings
The Port Settings page allows you to select ports that are detected by the loopback
detection function and configure their status (enabled or disabled).
To access this page, click L2 Switching > Loopback Detection > Port Settings.
Figure 4-51. L2 Switching > Loopback Detection > Port Settings
The following table describes the items in the previous figure.
The ensuing table for Loopback Detection Port Information settings are informational
only: Port, Enable State and Loop Status.
Table 4-49. L2 Switching > Loopback Detection > Port Settings
Item Description
Port Select Enter the port to define the local loopback detection setting.
Enabled Select Enabled or Disabled to setup the Loopback Detection function.
Apply Click Apply to save the values and update the screen.
