MANAGING SWITCH
83
Port Settings
The Port Settings page allows you to configure the port and the type of storm control
association along with the value of the storm rate for the selected port.
To access this page, click Security > Storm Control > Port Settings.
Figure 4-56. Security > Storm Control > Port Settings
The following table describes the items in the previous figure.
Table 4-54. Security > Storm Control > Port Settings
Item Description
Port Enter the port number to designate the local port for the Storm Control
function.
Port State Select Disabled or Enabled to define the port state
Action Click the drop-down menu to select the type of action to designate for the
selected port during a Storm Control incident. The options are Drop and
Shutdown.
Type Enable Click the radio button to enable Broadcast, Unknown Multicast, or
Unknown Unicast.
Broadcast: Select the variable in Kbps to define the broadcast
bandwidth.
Unknown Multicast: Select the variable in Kbps to define the multicast
setting.
Broadcast: Select the variable in Kbps to define the unknown unicast
setting.
Apply Click Apply to save the values and update the screen.
